Description
Stovax Studio inset wood burning fires are available in four sizes, each with a wide variety of frame options. From glass and steel to profil and bauhaus, there will be a frame to suit your own personal taste and style. Alternatively the Studio can be fitted with an Edge kit for a more minimalist appearance.
As a continuation from the Stovax Studio Edge, the Ecodesign Edge + inset wood burning fire provides a similarly frameless ‘hole in the wall’ fire look, yet offers the additional benefit of a more simplified finishing process.
A slim profile decorative frame, crafted from 1mm thick steel, overlays the finished wall surface and provides a perfectly crisp finish around the installation opening.
With a complementary Matt Black finish, the Studio Edge + inset fire is a sophisticated and functional styling option that simply lets the Studio’s impressive wood burning flame picture provide all the aesthetic appeal!
STUDIO EDGE + INFORMATION
| Fire sizes | Nominal Heat Output & Range |
Max log lengths | Frame dimensions mm (wxhxd) | Energy Efficiency Class |
|---|---|---|---|---|
| Studio 500 | 5.0kW (1.7-7kW) | 250mm (10”) | 700 x 573 x 34* | A |
| Studio 1 | 5.0kW (1.7-7kW) | 300mm (12”) | 785 x 463 x 1 | A |
| Studio 2 | 8.0kW (2.8-11.kW) | 400mm (16”) | 983 x 488 x 1 | A |
| Studio 3 | 11.0kW (3.8-16kW) | 500mm (20”) | 1372 x 493 x 1 | A |
Once installed, the Edge kits are flush with the finished wall surface. Edge + kit includes decorative frame
*Depth is adjustable between 32mm and 52mm between Edge + frame and kit when fitted
KEY FACTS
| Brand | Stovax |
| Ecodesign Plus | Yes |
| High efficiency | up to 80% |
| Wood burning | Yes |
| Boost setting for lighting and re-fueling | Yes |
| Removable steel and TCL baffles | Yes |
| TCL firebox lining | Yes |
| Radiant heat and convected heat | Yes |
| External air facility | Yes |
| Optional fan-assisted convection kit** | Yes |
| Optional warm air ducting system | Yes |
| Top flue connection | Internal Ø – 153mm (6”) |
| Suitable for Smoke Control Areas* | Yes |
* Sizes 500, 1 and 2 only. When fitted with a Smoke Control Kit and used in accordance with the operating instructions.
** Studio 2 and 3 sizes only.
